Multifactor Authentication – Cognitive overload?

smart phone face recognition, code, finger print and numeric password screens.

Recenty the FBI warned that cyber thieves are finding ways around multifactor authentication protections. We may not own crypto accounts, but universities across the UK have implemented forms of two or multi-factor authentication to protect our accounts and we are grappling with strategies to ensure accessible forms for verification are available. The W3C WCAG Cognitive and Learning Disabilities Task Force has published an Accessible Authentication (User Story) to illustrate the need for the cognitive function test mentioned in the previous blog. It also highlights how memory impairments and difficulties with executve function can make MFA a challenge as well as time constraints.

There was a Twitter stream in February 2021, that highlighted more reasons why some of the MFA choices offered may not be helpful to individuals with Autism and Attention Deficit Hyperacive Disorder (ADHD). Devon Price’s insight into the frustrating nature of these extra levels of security illustrates the cognitive overload that can occur when several tasks have to be completed with multiple devices or systems.

key fob

If you do not have an external code device, the choices tend to centre around the use of a personal mobile phone. Having checked the websites of 50 universities it appeared that 42 (84%) advised students to use an authenticator app – usually Microsoft, that also offers a Self Service Password Reset. Other options were the Authy, Google, Sophos or Duo apps. All the university systems still require the user to remember passwords with the extra verification and then encourage a back up option via SMS, a phone call and some mentioned a landline or email. Only 4 universities offered a choice of two authentication apps and just 7 mentioned the use of a fob or external device, although one said this would not to work with Virtual Personal Networks. Preference for Authy as an alternative was mentioned in a question about the Microsoft Authenticator, as this can be used on a desktop computer. At the time of writing Microsoft Authenticator instructions do not mention a desktop verification option to their MFA.

Some universities in the small study used the Microsoft instructions, but when searching for support it took well over 3 clicks, to find out about the authentication options offered by 14 out of the 50 universities (28%), 9 of these websites either had no information or required a log in. This meant that a new student may have no way of preparing for this aspect of registration, although all of the websites had good connections to their student support or IT services.

Only one university appeared to depend on a memorable word for verification and the use of authenticator apps usually meant that the code could be used without an internet connection or a connection to a mobile network provider. This does not mean that copying a code results in successful verification on all occasions.

Where concentration or attention is an issue, as may happen with ADHD, the problem of copying codes from one device to another can become worse as more attempts are made. Too many tries leads to lockout, desperation and yet another feeling of failure, let alone time wasting and other more severe consequences, if the actions are related to banking. Actions that involve recognition and copying qualify under the W3C WCAG cognitive function test as requiring an alternative method.

Using biometrics is often considered a good alternative, but it is not always easy to get facial recognition to work on phones if you are blind or have dexterity difficulties and some individuals really do not like sharing their facial image. The UK National Cyber Security Centre admits that fingers prints are not always recognised if people have been working in some industries or you are elderly and even a skin condition can cause problems. Also not all devices offer the chance of using finger recogntion.

In summary Making Content Usable for People with Cognitive and Learning Disabilities suggests four options:

  1. Web Authentication: An API for accessing Public Key Credentials [webauthn-2].
  2. Single Sign-on (SSO) that allow users to access many sites with a single login (federated login).
  3. Two step authentication with Bluetooth links (no copying).
  4. Quick Response Codes (QR Code).

The use of authentication apps, with a set up of 5 additional choices was offered by 6 of the 50 universities reviewed, so they provided more than the above options, plus the ability to use a helpline. When checking the helplines it became clear that there were often rather a lot of questions surrounding the Microsoft Authenticator, as evidenced by the University of Hertfordshire’s comprehensive set of answers. So It appears there is still much to do to make the process more inclusive.

Multifactor Authentication update WCAG 2.2

laptop with login and password

On January 13th, 2022, a W3C Editor’s draft of the Web Content Accessibility Guidelines (WCAG) 2.2 was published on GitHub. Among several updates and new items, it includes processes for making multifactor Authentication more accessible and easier to use. Systems for auto-filling are allowed, as well as copy and paste, so that one does not have always depend on remembering passwords. Email links and text messages are included for those happy with using other applications and devices.

This is welcome help for aspects of multifactor authentication that were described in a previous blog, even though the requirement is not at the hoped for top level. However, it has been set at Level AA, so hopefully this new Success Critera will still be offered by web services later this year. As was mentioned in August 2021, passing the check is based on overcoming what is called the cognitive function test

“A task that requires the user to remember, manipulate, or transcribe information. Examples include, but are not limited to:

  • memorization, such as remembering a username, password, set of characters, images, or patterns. The common identifiers name, e-mail, and phone number are not considered cognitive function tests as they are personal to the user and consistent across websites;
  • transcription, such as typing in characters;
  • use of correct spelling;
  • performance of calculations;
  • solving of puzzles. ” (WCAG 2.2)

It should be pointed out that this draft has yet to be approved, but WCAG have set June 2022 as the date for publication.

As an aside, there is no mention regarding the impact of biometrics (such as facial or finger print recognition) in the WCAG document, which can also be used to support access to web services, but are not available on all devices. These systems do not suit all users, and if passwords are not used as part of a login process these could present another type of barrier.

Time-based one-time passwords (TOTPs) can also cause problems when they have a very short period of use (30 seconds) and a person may fail to complete the action several times and then has to take a break. A January 2022 review by PC Mag UK highlighted the fact that Authenticator apps can offer better security, when compared to text messages (SMS). Some have desktop options that may also be more accessible.

Authentication Types: what they mean?

iris biometric scanning

You might have wondered what all those authentication types mentioned in our last blog actually meant? Some are well known, but a few are new, so it seemed to make sense to try to give each one a definition or explanation from the many sites that have this information! The result is a random collection of links. They may not be the best available and are certainly not academically based or tried and tested but here goes:

Knowledge: Something a person knows

  • Password – a string of characters that allows access to a computer system or service.
  • PIN – A personal identification number (PIN), or sometimes redundantly a PIN number, is a numeric (sometimes alpha-numeric) passcode used in the process of authenticating a user accessing a system.
  • Knowledge-based challenge questions – Knowledge-based authentication (KBA) is an authentication scheme in which the user is asked to answer at least one “secret” question.
  • Passphrase – A passphrase is a longer string of text that makes up a phrase or sentence.
  • Memorised swiping path – laying your finger on a screen and moving in any direction that covers the memorised characters.

Possession: Something a person has

  • Possession of a device evidenced by one time password (OTP) generated by, or received on a device – “The password or numbers sent to for instance a phone expire quickly and can’t be reused.”
    • Possession of a device evidenced by a signature generated by a device – “hardware or software tokens generate a single-use code to use when accessing a platform.”
    • Card or device evidenced by QR code scanned from an external device – “Quick Response (QR) code used to authenticate online accounts and verify login details via mobile scan or special device.”
    • App or browser with possession evidenced by device binding – “a security chip embedded into a device or private key linking an app to a device, or the registration of the web browser linking a browser to a device”
    • Card evidenced by a card reader – “physical security systems to read a credential that allows access through access control points.”
    • Card with possession evidenced by a dynamic card security code – “Instead of having a static three- or four-digit code on the back or front of the card, dynamic CVV technology creates a new code periodically.”

Inherence: Something about the person e.g. biometrics

  • Fingerprint scanning – “When your finger rests on a surface, the ridges in your fingerprints touch the surface while the hollows between the ridges stand slightly clear of it. In other words, there are varying distances between each part of your finger and the surface below. A capacitive scanner builds up a picture of your fingerprint by measuring these distances.”
  • Voice recognition – “Voice and speech recognition are two separate biometric modalities…By measuring the sounds a user makes while speaking, voice recognition software can measure the unique biological factors that, combined, produce [the] voice.”
  • Hand & face geometry – A biometric that identifies users from the shape of their hands and in the case of Google’s Media Pipe face identification it is complex network of 3D facial keypoints using artificial intellingence etc to analyse the results.
  • Retina & iris scanning – “both ocular-based biometric identification technologies… no person has the same iris or retina pattern”
  • Keystroke dynamics – …”keystroke dynamics don’t require an active input. Instead, keystroke dynamics analyzes the typing patterns of users; this can include typing rhythms, frequent mistakes, which shift keys they use for capitalization and pace.”
  • Angle at which device is held – “the exact angle a user holds the phone as a means of making replay attacks a lot more difficult.”

There has been a debate about which of the above should be considered under the various headings and acceptable as part of a secure multifactor authentication system. If you are interested in these processes and want more information it may be worth reading the Opinion of the European Banking Authority on the elements of strong customer authentication under PSD2. By the way PSD2 means ‘Payment Services Directive 2’ and the UK will be following the directive, but there is an extension for UK e-commerce transactions.

However, in the meantime many organisations other than banking, shopping sites and those that hold personal data have asked users to consider multifactor authentication including the NLive project lead and the University of Southampton that has some helpful instructions.
